Voice and GmPRS compatible
Ingen
| Frekvens | 1525 – 1559 MHz, 1626.5 – 1660.5 MHz, 1575.42 MHz |
|---|---|
| Gain | 0 dBic |
| Stik | SAT: N-female |
| Kabel | See “Part No.” (Other cables available) |
| Længde/højde | 301 mm |
| Montering | High grade AISI-316 stainless steel Mounting Bracket and mounting hardware included |
| Monteringssted | On pole or rail with supplied Mounting Bracket and U-bolts |
60101-013 – Antenna including Mounting Bracket
60101-043 – Kit: Antenna + 69001-000 DC-Feeder SMA
60101-053 – Kit: Antenna + 69002-000 DC-Feeder N
60101-063 – Kit: Antenna + DC-Feeder + 20 m Cable-Kit SMA/SMA
60101-073 – Kit: Antenna + DC-Feeder + 20 m Cable-Kit N/TNC
60101-083 – Kit: Antenna + DC-Feeder + 20 m Cable-Kit FME/SMA
91001-010 – 10 m Cable-Kit. SAT: N-male, GPS: SMA-male
91001-020 – 15 m Cable-Kit. SAT: N-male, GPS: SMA-male
91001-030 – 20 m Cable-Kit. SAT: N-male, GPS: SMA-male
91001-040 – 25 m Cable-Kit. SAT: N-male, GPS: SMA-male
91001-050 – 30 m Cable-Kit. SAT: N-male), GPS: SMA-male
91001-060 – 40 m Cable-Kit. SAT: N-male, GPS: SMA-male
91002-010 – 10 m Cable-Kit. SAT: N-male, GPS: TNC-male
91002-XXX – Customer specified Cable-Kit with SAT: N-male, GPS: TNC-male as above
Ingen
| Frekvens | 1525 – 1559 MHz, 1626.5 – 1660.5 MHz, 1575.42 MHz |
|---|---|
| Gain | 0 dBic |
| Stik | SAT: N-female |
| Kabel | See “Part No.” (Other cables available) |
| Længde/højde | 301 mm |
| Montering | High grade AISI-316 stainless steel Mounting Bracket and mounting hardware included |
| Monteringssted | On pole or rail with supplied Mounting Bracket and U-bolts |
