Low profile glass mounted multiband antenna
4-band self-adhesive linear patch antenna for in-car screen mounting
| Frekvens | 870 – 960 MHz, 1710 – 1890 MHz, 1850 – 1990 MHz, 1920 – 2170 MHz (GSM900/1800/1900/UMTS) |
|---|---|
| Gain | 0 dBd, 2.1 dBi |
| Stik | See “ORDERING INFORMATION” (Other connector types available) |
| Kabel | See “ORDERING INFORMATION” (Other lengths available) |
| Længde/højde | 8 mm |
| Montering | Adhesive pad |
| Monteringssted | In-car on screen |
| Max. effekt | 10 W |
20500 – 3 m cable + FME-female – in Polybag
20500IP – 3 m cable + FME-female – Bulk packing
20503IP – 0.3 m cable + SMA-male – Bulk packing
20514IP – 5 m cable + SMA-male – Bulk packing
20500IP – 3 m cable + FME-female – Bulk packing
20519IP – 0.3 m cable + FAKRA-D-female – Bulk packing
4-band self-adhesive linear patch antenna for in-car screen mounting
| Frekvens | 870 – 960 MHz, 1710 – 1890 MHz, 1850 – 1990 MHz, 1920 – 2170 MHz (GSM900/1800/1900/UMTS) |
|---|---|
| Gain | 0 dBd, 2.1 dBi |
| Stik | See “ORDERING INFORMATION” (Other connector types available) |
| Kabel | See “ORDERING INFORMATION” (Other lengths available) |
| Længde/højde | 8 mm |
| Montering | Adhesive pad |
| Monteringssted | In-car on screen |
| Max. effekt | 10 W |
