UHF 700 MHz Fourteen element Yagi Antenna
BY700-12G is a 14 element Yagi antenna with 12 dBd Gain.
| Frekvens | 660 – 800 MHz |
|---|---|
| Gain | 12 dBd, 14.15 dBi |
| Stik | Type N-female |
| Kabel | Approx. 0.5 m RG213/U |
| Længde/højde | 1400 x 240 mm |
| Montering | Fixed Tube Bracket in Galvanized Iron (included) |
| Monteringssted | On tube (Ø 20 – 65 mm, vertical or horizontal) |
| Max. effekt | 150 Watt |
