UHF 450 MHz Five element Yagi Antenna
BY70-7G is a 5 element Yagi antenna with 7 dBd Gain.
| Frekvens | T: 380 – 430 MHz 400 – 475 MHz |
|---|---|
| Gain | 7 dBd, 9.15 dBi |
| Stik | Type N-female |
| Kabel | Approx. 0.5 m RG213/U |
| Længde/højde | 1100 x 450 mm |
| Montering | Fixed Tube Bracket in Galvanized Iron (included – P05/01) |
| Monteringssted | On tube (Ø 20 – 65 mm, vertical or horizontal) |
| Max. effekt | 150 Watt |
BY70-7GT – 380 – 430 MHz In Box
BY70-7G – 400 – 475 MHz In Box
BY70-7G is a 5 element Yagi antenna with 7 dBd Gain.
| Frekvens | T: 380 – 430 MHz 400 – 475 MHz |
|---|---|
| Gain | 7 dBd, 9.15 dBi |
| Stik | Type N-female |
| Kabel | Approx. 0.5 m RG213/U |
| Længde/højde | 1100 x 450 mm |
| Montering | Fixed Tube Bracket in Galvanized Iron (included – P05/01) |
| Monteringssted | On tube (Ø 20 – 65 mm, vertical or horizontal) |
| Max. effekt | 150 Watt |
