UHF Low 350 MHz four element Yagi Antenna
BY300-7G is a 4 element Yagi antenna with 7 dBd Gain.
| Frekvens | BY300: 280- 330MHz BY360: 330- 380MHz |
|---|---|
| Gain | 7 dBd, 9.15 dBi |
| Stik | Type N-female |
| Kabel | Approx. 0.5 m RG213/U |
| Længde/højde | BY300: 1100 x 510mm BY360: 1000 x 420 mm |
| Montering | Fixed tube mounting bracket (included) |
| Monteringssted | On tube (Ø 20 – 65 mm, vertical or horizontal) |
| Max. effekt | 150 Watt |
BY300-7G – 280 – 330 MHz In Box
BY360-7G – 330 – 380 MHz In Box
BY300-7G is a 4 element Yagi antenna with 7 dBd Gain.
| Frekvens | BY300: 280- 330MHz BY360: 330- 380MHz |
|---|---|
| Gain | 7 dBd, 9.15 dBi |
| Stik | Type N-female |
| Kabel | Approx. 0.5 m RG213/U |
| Længde/højde | BY300: 1100 x 510mm BY360: 1000 x 420 mm |
| Montering | Fixed tube mounting bracket (included) |
| Monteringssted | On tube (Ø 20 – 65 mm, vertical or horizontal) |
| Max. effekt | 150 Watt |
