UHF Low 350 MHz Three element Yagi Antenna
BY300-5G is a 3 element Yagi antenna with 5 dBd Gain.
| Frekvens | BY300: 280- 330MHz BY360: 330- 380MHz |
|---|---|
| Gain | 5 dBd, 7.15 dBi |
| Stik | Type N-female |
| Kabel | Approx. 0.5 m RG213/U |
| Længde/højde | 780 x 450 mm |
| Montering | Fixed tube mounting bracket (included) |
| Monteringssted | On tube (Ø 20 – 65 mm, vertical or horizontal) |
| Max. effekt | 150 Watt |
BY300-5G – 280 – 330 MHz In box
BY360-5G – 330 – 380 MHz In box
BY300-5G is a 3 element Yagi antenna with 5 dBd Gain.
| Frekvens | BY300: 280- 330MHz BY360: 330- 380MHz |
|---|---|
| Gain | 5 dBd, 7.15 dBi |
| Stik | Type N-female |
| Kabel | Approx. 0.5 m RG213/U |
| Længde/højde | 780 x 450 mm |
| Montering | Fixed tube mounting bracket (included) |
| Monteringssted | On tube (Ø 20 – 65 mm, vertical or horizontal) |
| Max. effekt | 150 Watt |
