VHF 150 MHz Eight element Yagi Antenna
BY2-8G is a 8 element Yagi antenna with 10 dBd Gain.
| Frekvens | L: 144 – 160 MHz M: 153 – 167 MHz H: 160- 175 MHz |
|---|---|
| Gain | 10 dBd, 12.15 dBi |
| Stik | Type N-female |
| Kabel | Approx. 2.5 m RG213/U |
| Længde/højde | L: 2828 x 1040 mm M: 3270 x 960 H: 2990 x 880 |
| Montering | Fixed Tube Bracket in Galvanized Iron (included – P05/01) |
| Monteringssted | On Tube (Ø 20 – 65 mm, vertical or horizontal) |
| Max. effekt | 150 Watt |
BY2-10GL – 144 – 160 MHz In Box
BY2-10GM – 153 – 167 MHz In Box
BY2-10GH – 160 – 175 MHz In Box
BY2-8G is a 8 element Yagi antenna with 10 dBd Gain.
| Frekvens | L: 144 – 160 MHz M: 153 – 167 MHz H: 160- 175 MHz |
|---|---|
| Gain | 10 dBd, 12.15 dBi |
| Stik | Type N-female |
| Kabel | Approx. 2.5 m RG213/U |
| Længde/højde | L: 2828 x 1040 mm M: 3270 x 960 H: 2990 x 880 |
| Montering | Fixed Tube Bracket in Galvanized Iron (included – P05/01) |
| Monteringssted | On Tube (Ø 20 – 65 mm, vertical or horizontal) |
| Max. effekt | 150 Watt |
