Dual Band 2.4 / 5.8 WIFI Antenna 5 dBd (7,1 dBi)
The BC2455-5G is a lightweight dual band WiFi omnidirectional antenna with integrated mounting bracket.
| Frekvens | 2400 – 2485, 5150 – 5850 MHz (IEEE 802.11 (WLAN) a/b/g/h/n/p/ac) |
|---|---|
| Gain | 4 dBd, 6,1 dBi (2400 – 2485 MHz) 6 dBd, 8,1 dBi (5150 – 5850 MHz) |
| Stik | N-female |
| Længde/højde | Ø25 x 510 mm |
| Montering | Fixed Tube Mounting Bracket (included). Wall mount Bolts not included |
| Monteringssted | On Tube (Ø 40- 50 mm, vertical or Wall mount |
| Max. effekt | 20 W |
| IP-klasse | IP65 |
