VHF 150 MHz 3 dBd Omni Base Station Antenna
This meticulously constructed base station antenna with integrated multipurpose mounting bracket comes with a generous bandwidth which reduces the need for multiple antennas both in stock and on installation sites.
| Frekvens | 137-174 MHz – please find specification under “Ordering information” X-version 136-174 MHz – factory adjusted |
|---|---|
| Gain | 3 dBd, 5.15 dBi |
| Stik | Type N-female |
| Længde/højde | 3.6 m |
| Montering | Fixed Tube Mounting Bracket. Stainless Steel Mounting Hardware included. |
| Monteringssted | On vertical mast tube; Ø 30 – 60 mm |
| Max. effekt | 150 Watt |
| IP-klasse | IP66 |
BC2-3G/141 – BC2-3G 138-144 MHz 3 dBd / 5,1 dBi
BC2-3G/144 – BC2-3G 141-147 MHz 3 dBd / 5,1 dBi
BC2-3G/147 – BC2-3G 144-150 MHz 3 dBd / 5,1 dBi
BC2-3G/150 – BC2-3G 147-153 MHz 3 dBd / 5,1 dBi
BC2-3G/153 – BC2-3G 150-156 MHz 3 dBd / 5,1 dBi
BC2-3G/156 – BC2-3G 153-159 MHz 3 dBd / 5,1 dBi
BC2-3G/159 – BC2-3G 156-162 MHz 3 dBd / 5,1 dBi
BC2-3G/162 – BC2-3G 159-165 MHz 3 dBd / 5,1 dBi
BC2-3G/165 – BC2-3G 162-168 MHz 3 dBd / 5,1 dBi
BC2-3G/168 – BC2-3G 165-171 MHz 3 dBd / 5,1 dBi
BC2-3G/171 – BC2-3G 168-174 MHz 3 dBd / 5,1 dBi
BC2-3G/X – BC2-3G/X 136-174 MHz 3 dBd / 5,1 dBi Factory-adjusted / BW6-7 MHz
