UHF96 – 6 dB UHF Fiberglass Antenna 1.14–1.34 m (806–960 MHz, available in 3 versions)

6 dB UHF Fiberglass Antenna 1.14–1.34 m (806–960 MHz, available in 3 versions)

Description

Variants

Downloads

Accessories

Description

None

3 standard band versions
Specified antenna for GSM850, GSM900, trunking, ISM, and others.
End-fed 1/2 λ Coaxial Dipole Antenna Design
Full omni-directional radiation pattern
No groundplane needed

Specifications

Frequency	806–866 MHz, 824–894 MHz, 890–960 MHz
Gain	6 dB (Marine), 3 dBd, 5.1 dBi
Connector	N-female
Cable	No cable included
Length/Height	Max. 1340 mm (“A” version)
Installation	On a 1″ threaded pole (G1″-11 thread) with the Revolving Nut Kit or on optional brackets
Installation Location	On mast or deck
Max. power	200 W
IP Rating	IP66

Model Variants

14096-000A – 806–866 MHz (Antenna only – bulk packaging)
14096-001A – 806–866 MHz (Antenna only – in polybag)
14096-002A – 806–866 MHz (Antenna only – in a cardboard tube)
14096-000B – 824–894 MHz (Antenna only – bulk packaging)
14096-001B – 824–894 MHz (Antenna only – in polybag)
14096-002B – 824–894 MHz (Antenna only – in a cardboard tube)
14096-000C – 890–960 MHz (Antenna only – bulk packaging)
14096-001C – 890–960 MHz (Antenna only – in polybag)
14096-002C – 890–960 MHz (Antenna only – in a cardboard tube)

Variants

Downloads

Accessories

Beskrivelse

Downloads

Beskrivelse

None

3 standard band versions
Specified antenna for GSM850, GSM900, trunking, ISM, and others.
End-fed 1/2 λ Coaxial Dipole Antenna Design
Full omni-directional radiation pattern
No groundplane needed

Specifications

Frequency	806–866 MHz, 824–894 MHz, 890–960 MHz
Gain	6 dB (Marine), 3 dBd, 5.1 dBi
Connector	N-female
Cable	No cable included
Length/Height	Max. 1340 mm (“A” version)
Installation	On a 1″ threaded pole (G1″-11 thread) with the Revolving Nut Kit or on optional brackets
Installation Location	On mast or deck
Max. power	200 W
IP Rating	IP66

Model Variants

14096-000A – 806–866 MHz (Antenna only – bulk packaging)
14096-001A – 806–866 MHz (Antenna only – in polybag)
14096-002A – 806–866 MHz (Antenna only – in a cardboard tube)
14096-000B – 824–894 MHz (Antenna only – bulk packaging)
14096-001B – 824–894 MHz (Antenna only – in polybag)
14096-002B – 824–894 MHz (Antenna only – in a cardboard tube)
14096-000C – 890–960 MHz (Antenna only – bulk packaging)
14096-001C – 890–960 MHz (Antenna only – in polybag)
14096-002C – 890–960 MHz (Antenna only – in a cardboard tube)
