UHF 450 MHz 7 dBd Omni Base Station Antenna
This meticulously constructed base station antenna with integrated multipurpose mounting bracket comes with a generous bandwidth which reduces the need for multiple antennas both in stock and on installation sites.
| Frekvens | 375 – 475 MHz |
|---|---|
| Gain | 7.0 dBd, 9.15 dBi |
| Stik | Type N-female |
| Længde/højde | 4.2 m |
| Montering | Fixed Tube Mounting Bracket. Stainless Steel Mounting Hardware included. |
| Monteringssted | On vertical mast tube; Ø 30 – 60 mm |
| Max. effekt | 150 Watt |
| IP-klasse | IP66 |
