UHF93 – 3 dB UHF Fiberglass Antenna 0.44 m (806–960 MHz, available in 3 versions)

3 dB UHF Fiberglass Antenna, 0.44 m (806–960 MHz, available in 3 versions)

Description

Variants

Downloads

Accessories

Description

None

3 standard band versions
Specified antenna for GSM850, GSM900, trunking, ISM, and others.
End-fed 1/2 λ Coaxial Dipole Antenna Design
Full omni-directional radiation pattern
No groundplane needed

Specifications

Frequency	806–866 MHz, 824–894 MHz, 872–960 MHz
Gain	3 dB (Marine), 0 dBd, 2.1 dB
Connector	N-female
Cable	No cable included
Length/Height	440 mm
Installation	On a 1″ threaded pole (G1″-11 thread) with the Revolving Nut Kit or on optional brackets
Installation Location	On mast or deck
Max. power	200 W
IP Rating	IP66

Model Variants

14093-000A – 806–866 MHz (Antenna only – bulk packaging)
14093-001A – 806–866 MHz (Antenna only – in polybag)
14093-002A – 806–866 MHz (Antenna only – in a cardboard tube)
14093-000B – 824–894 MHz (Antenna only – bulk packaging)
14093-001B – 824–894 MHz (Antenna only – in polybag)
14093-002B – 824–894 MHz (Antenna only – in a cardboard tube)
14093-000C – 872–960 MHz (Antenna only – bulk packaging)
14093-001C – 872–960 MHz (Antenna only – in polybag)
14093-002C – 872–960 MHz (Antenna only – in a cardboard tube)
