9 dB UHF Fiberglass Antenna, 0.84 m (1850–1990 MHz)
None
| Frequency | 1850–1990 MHz |
|---|---|
| Gain | 9 dB (Marine), 5 dBd, 7.1 dBi |
| Connector | N-female |
| Cable | No cable included |
| Length/Height | Approx. 840 mm |
| Installation | On a 1″ threaded pole (G1″-11 thread) with the Revolving Nut Kit or on optional brackets |
| Installation Location | On mast or deck |
| Max. power | 100 W |
| IP Rating | IP66 |
14199-000 – Antenna only – bulk packaging
14199-001 – Antenna only – in polybag
14199-002 – Antenna only – in cardboard tube
14199-431 – Antenna + 1″ Revolving Nut Kit – in polybag
14199-432 – Antenna + 1″ Revolving Nut Kit – in cardboard tube
None
| Frequency | 1850–1990 MHz |
|---|---|
| Gain | 9 dB (Marine), 5 dBd, 7.1 dBi |
| Connector | N-female |
| Cable | No cable included |
| Length/Height | Approx. 840 mm |
| Installation | On a 1″ threaded pole (G1″-11 thread) with the Revolving Nut Kit or on optional brackets |
| Installation Location | On mast or deck |
| Max. power | 100 W |
| IP Rating | IP66 |
