HF6200 RX – 6-meter three-part LF/MF/HF fiberglass antenna with coaxial connection box

6-meter three-part LF/MF/HF fiberglass antenna with coaxial connection box

Description

Variants

Downloads

Accessories

Description

None

High-quality 6-meter-high HF antenna for professional use
Built-in matching transformer for low-frequency reception
Rugged design
Chrome-plated solid brass joints
Designed for rail mounting
Connect via the screw terminal inside the connection box using standard coaxial cable (Ø 5–10 mm)
Full omni-directional reception pattern

Specifications

Frequency	0.15–30 MHz (LF, MF, and HF)
Connector	Screw terminal inside the connection box
Cable	No cable included (Use a standard coaxial cable with a diameter of 5–10 mm)
Length/Height	6 m
Installation	Rail Bracket Kit (Small) P/N 10000-153 (Not included!)
Installation Location	On a rail or pole (Ø 30–90 mm)
Max. power	n/a (Receive only)

Variants

Downloads

Accessories

Beskrivelse

Downloads

Beskrivelse

None

High-quality 6-meter-high HF antenna for professional use
Built-in matching transformer for low-frequency reception
Rugged design
Chrome-plated solid brass joints
Designed for rail mounting
Connect via the screw terminal inside the connection box using standard coaxial cable (Ø 5–10 mm)
Full omni-directional reception pattern

Specifications

Frequency	0.15–30 MHz (LF, MF, and HF)
Connector	Screw terminal inside the connection box
Cable	No cable included (Use a standard coaxial cable with a diameter of 5–10 mm)
Length/Height	6 m
Installation	Rail Bracket Kit (Small) P/N 10000-153 (Not included!)
Installation Location	On a rail or pole (Ø 30–90 mm)
Max. power	n/a (Receive only)
