UHF Low 350 MHz Ten-Element Yagi Antenna
The BY300-7G is a 10-element Yagi antenna with 12 dBd gain.
| Frequency | BY300: 280–330 MHz BY360: 330–380 MHz |
|---|---|
| Gain | 12 dBd, 14.15 dBi |
| Connector | Type N female |
| Cable | Approx. 0.5 m RG213/U |
| Length/Height | BY300: 2300 × 525 mm BY360: 2105 × 420 mm |
| Installation | Fixed tube mounting bracket (included) |
| Installation Location | On tube (Ø 20–65 mm, vertical or horizontal) |
| Max. power | 150 watts |
BY300-12G – 280–330 MHz In Box
BY360-12G – 330–380 MHz In Box
The BY300-7G is a 10-element Yagi antenna with 12 dBd gain.
| Frequency | BY300: 280–330 MHz BY360: 330–380 MHz |
|---|---|
| Gain | 12 dBd, 14.15 dBi |
| Connector | Type N female |
| Cable | Approx. 0.5 m RG213/U |
| Length/Height | BY300: 2300 × 525 mm BY360: 2105 × 420 mm |
| Installation | Fixed tube mounting bracket (included) |
| Installation Location | On tube (Ø 20–65 mm, vertical or horizontal) |
| Max. power | 150 watts |
